2022 KLX110

Starting from £2,619.00

6 months parts only Kawasaki Manufacturer Warranty Included

Description & Specification


Small bike equals big fun in the KLX110. This is where the adventure starts. The KLX110 is a versatile off-road bike with a low seat height, plush suspension and an automatic clutch for a fun, confidence-inspiring ride.

Available – June 2021

  • Engine

    Engine type

    Air-cooled, 4-stroke Single

    Displacement

    112 cm

    Bore x stroke

    53.0 x 50.6 mm

    Compression ratio

    9.5:1

    Valve/Induction system

    SOHC, 2 valves

    Fuel system

    Carburettor: PB18 (Keihin)

    Ignition

    Digital DC-CDI

    Starting

    Electric and Kick

  • Transmission

    Transmission

    4-speed

    Final Drive

    Chain

    Primary reduction ratio

    3.409 (75/22)

    Gear ratios: 1st

    3.000 (36/12)

    Gear ratios: 2nd

    1.938 (31/16)

    Gear ratios: 3rd

    1.350 (27/20)

    Gear ratios: 4th

    1.087 (25/23)

    Gear ratios: 5th

    Final reduction ratio

    2.923 (38/13)

    Clutch

    Centrifugal, wet multi-disc

  • Frame

    Frame type

    Backbone, Steel

    Rake/Trail

    50 mm

    Wheel travel - front

    110 mm

    Wheel travel - rear

    110 mm

    Tyre - front

    2.50-14 (4PR)

    Tyre - rear

    3.00-12 (4PR)

    Steering angle - left / right

    45 / 45

  • Suspension

    Suspension - front

    30 mm telescopic fork

    Suspension - rear

    Single shock

  • Brakes

    Brakes - front

    Drum ( 90 mm)

    Brakes - rear

    Drum (110 mm)

  • Dimensions

    Dimensions (L x W x H)

    1,560 x 650 x 955 mm

    Wheelbase

    1,075 mm

    Seat height

    680 mm

    Fuel capacity

    3.6 litres

    Curb Mass

    76 kg
